Everything Sovol Sv06

A repository containing specifications of the Sovol SV06 3D printer. ⭐ Star to support this work!

Overview

Everything Sovol SV06

A repository containing specifications of the Sovol SV06 3D printer parts, as well as links to aftermarket replacement parts.

You can assume that all information herein is accurate unless stated otherwise.

You can also contribute by making a pull-request, creating an issue, or starting a discussion.

Support Me ❤️

Please ⭐ star this repository! Support open source, and buy me a <img src="./images/misc/logo_white_stroke.png" height="20" alt='Ko-fi'/>.

Some of the links found on this page may be affiliate links.

Contents

1. Initial Setup Steps
2. Print Head
   • PCB
   • Hotend
     • Heater Cartridge
     • Thermistor
     • Heatbreak
     • Nozzle
   • Filament Sensor
   • Probe
   • Fans
   • Extruder
3. Motherboard
4. Motion System
   • Lead Screws
   • POM Nuts
   • Linear Motion Guide Rods
   • Linear Bearings
   • Z Axis Couplers
   • Belts
   • Stepper Motors
5. Power Supply
6. How To 🛠️
7. Links
8. Sample Prints 🍰
9. Printed Upgrades 🏗️
10. Modifications 🪚

Stay Up-to-Date

This repository is a work in progress. Watch for updates:

<img src="./images/misc/githubstar.gif" width="500" alt='Github star'/>

Files in this package

• CAD source: extruderevolved.step
• Exports: E-steps calibration tool 100mm.stl, E-steps calibration tool 200mm.stl, SV06-heatbed-cable-support-V2.stl, jig-hose-cutter-D10mm-L14mm.3mf, sv06_strain_relief_v1.stl, sv06_strain_relief_v2.stl, sv06_strain_relief_v3.stl
• Images: 20230304.SOVOL.SV06.02.jpg, 20230304.SOVOL.SV06.03.jpg, amonite.webp, heatblock-display.jpg, heatbreak.png, lead-rod.webp, lead-screw.webp, linear-bearings.webp, linear-bearings2.webp, logo_white_stroke.png, screws_tilt_calculate.png, smooth-idler.jpg
• Documents: extruderevolved.pdf

---
